Conveyor Coupling: Which Type and How to Size a Gear Coupling

How to select gear couplings for conveyor drives: torque, start/stop duty, and alignment.

To select a gear coupling for a conveyor system, calculate design torque as 9,550 × kW ÷ rpm × service factor and choose a coupling rated above it. A 75 kW motor at 1,480 rpm with a service factor of 2.0 needs 968 Nm. Size a gearbox-to-pulley coupling separately: after a 20:1 reducer, torque is about 20 times higher.

Which coupling type suits a conveyor?

The coupling depends on where it sits in the drive and how much shock the conveyor sees. The low-speed shaft between gearbox and head pulley carries the most torque and is where gear and chain couplings are used. The high-speed shaft between motor and gearbox carries far less torque, and on light conveyors a flexible elastomer coupling is usually enough there.

CouplingWhere it fits on a conveyorSMI range
Full gear couplingGearbox to head pulley, and motor to gearbox on heavy, long or loaded-start conveyorsFG-100 to FG-119, 559 to 1,666,744 Nm, bores to 710 mm
Chain couplingLow-speed, high-torque positions where a compact, easily split coupling is wanted3812 to 40028, 99 to 717,000 Nm, bores to 670 mm
RRS pin bush couplingMotor to gearbox where the rubber bushes should absorb starting shockSee the product page for sizes
HRC couplingMotor to gearbox on small conveyors with smooth loadsSHRC 70 to SHRC 280, 31 to 3,150 Nm, bores to 130 mm
Star couplingLight conveyors and small drivesSJC 75 to SJC 295, 9.8 to 1,279 Nm, bores to 100 mm
Brake drum gear couplingInclined or reversing conveyors that need a brake on the driveSee the product page for sizes

Whatever the type, size it on design torque, 9,550 × kW ÷ rpm × service factor, using 1.25 to 1.50 for a belt conveyor from the coupling service factor chart, and add 0.25 if it starts more than four times an hour.

Conveyor Drive Challenges

Operating Conditions

Conveyor couplings must handle:

  • Frequent starts and stops causing torque spikes
  • Loaded starts with belt carrying material
  • Environmental exposure to dust, moisture, temperature
  • Continuous operation for extended periods
  • Misalignment from thermal growth and foundation issues

Coupling Location

Typically installed between:

  • Motor and gearbox (high speed)
  • Gearbox and head pulley (high torque)
  • Both positions in large systems

Selection Process

Step 1: Calculate Design Torque

Formula: Design Torque = (Motor Power × 9550) / Speed × Service Factor

Example:

  • Motor: 75 kW at 1480 RPM
  • Service factor: 2.0
  • Design torque: (75 × 9550) / 1480 × 2.0 = 968 Nm

Step 2: Determine Service Factor

Conveyor Type Service Factor
Light duty, uniform load 1.5
General purpose 1.75-2.0
Mining, heavy loading 2.0-2.5
Frequent starts, loaded 2.5-3.0

Step 3: Consider Speed and Size

Match coupling to position in drivetrain:

Position Speed Torque Coupling Type
Motor-Gearbox High Lower Standard full gear
Gearbox-Pulley Low Higher Heavy duty gear

Special Considerations

Starting Torque

Conveyors require higher starting torque:

  • Belt and material inertia
  • Static friction breakaway
  • Motor starting characteristics

Rule: Starting torque may reach 200-250% of running torque

Alignment Challenges

Conveyors experience alignment changes (see the gear coupling alignment checklist) from:

  • Thermal expansion of long structures
  • Belt tension variations
  • Foundation settling
  • Pulley wear and bearing play

Solution: Select couplings with adequate misalignment capacity

Environmental Factors

Environment Coupling Features
Dusty Enhanced sealing, labyrinth design
Wet Corrosion-resistant finish
Hot High-temperature grease
Cold Low-temperature grease, ductile materials

Recommended Coupling Types

Head Drive Applications

High-torque, low-speed position:

  • Full gear couplings
  • Heavy-duty designs
  • Robust sealing for dust

Motor-Gearbox Connection

High-speed, moderate torque:

  • Standard gear couplings
  • Good for acceleration loads
  • Precision balanced for high RPM

Take-Up or Tail End

If driven:

  • Moderate duty couplings
  • Spacer type for maintenance access
  • Good dust exclusion

Installation Best Practices

Alignment Targets

Parameter Maximum Allowable
Angular 0.5° per gear mesh
Offset 50% of allowable
Axial gap Per coupling spec

Mounting Sequence

  1. Install motor and gearbox on machined pads
  2. Mount coupling halves to shafts
  3. Perform rough alignment
  4. Complete final cold alignment
  5. Record readings for reference
  6. Recheck alignment after heat stabilization

Maintenance Schedule

Routine Inspection

Interval Check
Daily Unusual noise, vibration, leaks
Weekly Temperature during operation
Monthly Visual condition of seals
Quarterly Relubrication, alignment verification
Annually Comprehensive inspection

Common Issues

Symptom Possible Cause Action
High temperature Misalignment, low grease Realign, relubricate
Vibration Coupling wear, imbalance Inspect, replace worn parts
Noise Dry operation, tooth wear Lubricate, check wear
Grease leakage Seal failure, overfilling Replace seals, correct fill

SMI Conveyor Coupling Solutions

We offer gear couplings specifically suited for conveyor applications:

  • Full and half gear couplings in 20 sizes, FG-100 to FG-119
  • Rated 559 to 1,666,744 Nm, with bores up to 710 mm (size chart)
  • Enhanced sealing options
  • Quick delivery for standard sizes

Contact SMI for conveyor coupling selection support and quotations.

Frequently asked questions

Where does the coupling sit on a conveyor drive?

Usually between motor and gearbox, and sometimes between gearbox output and the drive pulley shaft. The torque is very different in the two positions — a 15 kW motor at 1,440 RPM is about 100 Nm at the motor shaft but roughly 2,000 Nm after a 20:1 reducer. Always state which position you are specifying for.

What service factor should a conveyor drive use?

Around 1.25 for a uniformly fed belt running up to ten hours a day, 1.4 to 1.5 for continuous running with non-uniform feed, and 1.5 for bucket elevators. Add more if the belt regularly starts loaded, since breakaway torque is far higher than running torque.

Should I use a shaft mounted reducer instead of a foot-mounted gearbox and coupling?

On conveyors and elevators, often yes. A shaft mounted speed reducer sits directly on the driven shaft with a torque arm, removing the base plate, the coupling and the alignment job. We manufacture SMSR units in 5:1, 13:1 and 20:1 ratios covering 0.5 to 50 kW.
