How to Measure Shaft and Select Bore and Key
Accurate shaft measurement techniques and coupling bore selection guidance.
Accurate shaft measurement is essential for proper gear coupling fit. This guide covers measurement techniques and bore/key selection to ensure reliable coupling installation.
Why Accuracy Matters
Incorrect measurements lead to:
- Poor coupling fit (too loose or tight)
- Fretting damage
- Key failure
- Hub cracking
- Vibration problems
Shaft Measurement Techniques
Required Tools
- Micrometer (accuracy 0.01mm)
- Vernier caliper (for reference)
- Depth micrometer (for keyway)
- Dial indicator (for runout)
- Steel rule
Step 1: Clean the Shaft
- Remove all rust, paint, burrs
- Clean with solvent if oily
- Inspect for damage
- Mark measurement locations
Step 2: Measure Diameter
At multiple points:
- At coupling mounting position
- At inboard and outboard of mount zone
- In two planes 90° apart
Record readings:
| Location | Plane 1 | Plane 2 |
|---|---|---|
| Inboard | ||
| Center | ||
| Outboard |
Calculate:
- Average diameter
- Out-of-round (max - min)
- Taper (end to end difference)
Step 3: Measure Keyway
Dimensions needed:
- Width at bottom and top
- Depth from shaft surface
- Length
- Corner radii
Standard Check:
| Dimension | Tolerance |
|---|---|
| Width | +0.025 to +0.050mm |
| Depth | As per standard |
| Corners | Clean, no burrs |
Step 4: Check Runout
Mount dial indicator and rotate shaft:
- Record TIR (Total Indicator Reading)
- Acceptable: <0.05mm for precision
- Marginal: 0.05-0.10mm
- Problem: >0.10mm
Selecting Bore Size
Standard Fits
| Fit Type | Application | Tolerance |
|---|---|---|
| Clearance (H7/g6) | Easy assembly, light duty | Gap exists |
| Transition (H7/k6) | Moderate duty, removable | Light interference |
| Interference (H7/p6) | Heavy duty, permanent | Press/heat fit |
Recommended for Gear Couplings
| Application | Recommended Fit |
|---|---|
| General industrial | H7/k6 (transition) |
| Heavy duty | H7/p6 (interference) |
| Frequent removal | H7/h6 (close running) |
Interference Calculation
For interference fit, calculate expansion:
Heating temperature:
ΔT = (Interference + 0.05) / (Bore × 11.7 × 10⁻⁶)
Where:
- Interference in mm
- Bore in mm
- Result in °C
Selecting Key Size
Standard Key Selection
Key size based on shaft diameter:
| Shaft Dia (mm) | Key Width × Height |
|---|---|
| 22-30 | 8 × 7 |
| 30-38 | 10 × 8 |
| 38-44 | 12 × 8 |
| 44-50 | 14 × 9 |
| 50-58 | 16 × 10 |
| 58-65 | 18 × 11 |
| 65-75 | 20 × 12 |
| 75-85 | 22 × 14 |
Key Fit Requirements
In shaft keyway:
- Side fit: Close running or light interference
- Bottom fit: Clearance
In hub keyway:
- Side fit: Transition or interference
- Top fit: Clearance
Key Length
Minimum length:
L_min = T / (σ × b × d)
Where:
- T = Torque
- σ = Allowable stress
- b = Key width
- d = Shaft diameter
Rule of thumb: Key length ≈ 1.0 to 1.5 × shaft diameter
Common Mistakes
| Mistake | Consequence | Prevention |
|---|---|---|
| Single measurement | Miss taper or out-of-round | Multiple locations |
| Dirty shaft | Incorrect reading | Clean thoroughly |
| Wrong key size | Failure, damage | Use standard tables |
| Loose key | Shear, fretting | Proper fit |
| Tight bottom fit | Key lifts hub | Bottom clearance |
Documentation
Record all measurements:
- Date and location
- Equipment identification
- All readings with positions
- Calculated values
- Selected bore and key sizes
- Any noted issues
